Markdown, Pandoc and Quarto

a modern ecosystem for typesetting and publishing

Julien Vitay

julien.vitay@informatik.tu-chemnitz.de

Chemnitz University of Technology

Why Markdown?

The two main approaches to generating documents (reports, slides, etc) are Office suites (MS, Google, Libre…) and LaTeX.

Office

Pros:

WYSIWYG
Collaboration (review mode, google doc)

Cons:

Version conflicts.
Reproducibility.
Math equations and bibliography are not great.

LaTeX

Pros:

Beautiful documents (but not beamer slides).
Reproducibility.

Cons:

Horrible markup language.
Compilation is slow.
Only outputs pdf (no video in your slides).

Both are additionally not great at generating html \rightarrow third ecosystem.

1 - Markdown

Basic Markdown syntax

Markdown is a markup language (as html, tex, wiki, rst…) initially developed to write basic documents (e.g. README files or blocks in Jupyter notebooks).

Latex

\textbf{Bold text} \textit{Italic text}  \verb?Verbatim?

\begin{itemize}
  \item Item 1
  \item Item 2
\end{itemize}

\begin{enumerate}
  \item Item 1
  \item Item 2
\end{enumerate}

\section{First header}
\subsection{Second header}
\subsubsection{Third header}

\href{https://julien-vitay.net}{My website}
\url{https://julien-vitay.net}

Markdown

**Bold text** *Italic text* `Verbatim`

* Item 1
* Item 2

1. Item 1
2. Item 2

# First header
## Second header
### Third header


[https://julien-vitay.net](My website)
<https://julien-vitay.net>

Images

Latex

\includegraphics{img/ai.png}

\begin{figure}[htbp]
    \centering
    \includegraphics[width=0.5\textwidth]{img/ai.png}
    \caption{The logo of the lab.}
    \label{fig:mesh1}
\end{figure}

Markdown

![](img/ai.webp)

![The logo of the lab.](img/ai.webp){width=50%}

Tables

Latex

\begin{tabular}{|ccc|}
 \hline
 Column 1 & Column 2 & Column 3 \\
 \hline \hline
 item 11 & item 12 & item 13 \\
 \hline
 item 21  & item 22  & item 23  \\
\hline
\end{tabular}

Markdown

| Column 1 | Column 2 | Column 3 |
| -------- | -------- | -------- |
| item 11  | item 12  | item 13  |
| item 21  | item 22  | item 23  |

Rendered

Column 1	Column 2	Column 3
item 11	item 12	item 13
item 21	item 22	item 23

See https://www.tablesgenerator.com/markdown_tables for easier design of tables.

Code blocks

Latex

\begin{lstlisting}
import numpy as np
import ANNarchy as ann

P = ann.Population(geometry=1000, neuron=ann.Izhikevich)
E = P[:800] ; I = P[800:]

EI = ann.Projection(pre=E, post=P, target='exc')
EI.connect_all_to_all(weights=ann.Uniform(0.0, 0.5))

IE = ann.Projection(pre=I, post=P, target='inh')
IE.connect_all_to_all(weights=ann.Uniform(0.0, 1.0))

ann.compile()

ann.simulate(1000.0, measure_time=True)
\end{lstlisting}

Markdown

```python
import numpy as np
import ANNarchy as ann

P = ann.Population(geometry=1000, neuron=ann.Izhikevich)
E = P[:800] ; I = P[800:]

EI = ann.Projection(pre=E, post=P, target='exc')
EI.connect_all_to_all(weights=ann.Uniform(0.0, 0.5))

IE = ann.Projection(pre=I, post=P, target='inh')
IE.connect_all_to_all(weights=ann.Uniform(0.0, 1.0))

ann.compile()

ann.simulate(1000.0, measure_time=True)
```

Code blocks with syntax highlighting are available for many languages: python, cpp, latex, java, html, etc.

Equations

Both LaTeX and Markdown use the same mathematical description for equations, both inline and as blocks, using the $$ environment:

The firing rate $r_j (t)$ of the $j$-th neuron in the population follows the following equation:

$$
  \tau \, \dfrac{d r_j(t)}{dt} + r_j(t) = \sum_{i=1}^N w_{i, j} \, r_i (t)^+ + B_j
$$

The firing rate r_j (t) of the j-th neuron in the population follows the following equation:

\tau \, \dfrac{d r_j(t)}{dt} + r_j(t) = \sum_{i=1}^N w_{i, j} \, r_i (t)^+ + B_j \tag{1}

2 - Pandoc

Pandoc

Many tools are available to produce documents (html, pdf) from Markdown files, sometimes using modifications of the syntax (e.g. Github-flavoured Markdown).
Pandoc is an amazing converter from Markdown to many other formats (html, latex, docx, odt, wiki) and back, with its own extension of the Markdown syntax and templates.

pandoc file.md --template=nature.tex -o file.pdf

Cross-references

As \label{} and \ref{} in LaTeX, Pandoc’s markdown allows the use of cross-references in documents.
The label must be preceded by the type of the object, e.g. sec-, fig-, eq-, tbl-.
# is for the label, @ for the call, including the prefix (Figure, Equation).

# Introduction {#sec-introduction}

![The logo of the lab.](img/ai.webp){#fig-logolab width=50%}

$$
  \tau \, \dfrac{d r_j(t)}{dt} + r_j(t) = \sum_{i=1}^N w_{i, j} \, r_i (t)^+ + B_j
$$ {#eq-neuron}

@sec-introduction, @fig-logolab, @eq-neuron

renders the refs as:

Section 1, Figure 1, Equation 1

The prefix (Figure, etc) can be modified in a parameter file, for example for internationalization.

Bibliography

Pandoc can use bibtex files to generate the bibliography automatically.
The path to the bib file and the CSL style can be declared as a variable in the CLI or in the YAML preamble of the file:

---
title: Markdown, Pandoc and Quarto
subtitle: a modern ecosystem for typesetting and publishing
author: Julien Vitay

bibliography: references.bib
csl: frontiers.csl
---

@Vitay2015 introduced ANNarchy [@Scholl2022]

Vitay et al. (2015) introduced ANNarchy (Scholl et al., 2022)

Any citation style can be used when available at https://citationstyles.org.
The references are automatically added at the end of the document.

Divs

Divs allow to apply a CSS class or a LaTeX environment on some content.
Three colons (:::) start and stop the div, using curly braces or directly the tag if there is only one.
Examples with callouts:

::: {.callout-note}
Content
:::

or simply

::: callout-warning
Content
:::

Note

Content

Warning

Content

Two columns (especially for slides)

::: columns
::: column

* Content of left column

:::
::: column

* Content of second column

:::
:::

Footer:

::: footer
Footer only for this slide
:::

Divs are mostly for html, but some are also available for pdf.

3 - Quarto

Quarto

pandoc can convert any .md file into any format, but writing the right template can be quite cumbersome.
Quarto is a publishing platform based on pandoc that allows to quickly get beautiful websites / books / articles / presentations (reveal.js) …
Jupyter notebooks can even be used to generate (live) html pages and pdfs. The quarto file format is .qmd.

Python code

You can call Python / R / Julia code directly from a quarto document, and render the result, such as a Matplotlib plot:

```{python}
#| label: fig-polar
#| fig-cap: "A line plot on a polar axis"

import numpy as np
import matplotlib.pyplot as plt

r = np.arange(0, 2, 0.01)
theta = 2 * np.pi * r
fig, ax = plt.subplots(
  subplot_kw = {'projection': 'polar'}
)
ax.plot(theta, r)
ax.set_rticks([0.5, 1, 1.5, 2])
ax.grid(True)
plt.show()
```

Video extension

Quarto has extensions to use special (javascript) libraries, e.g. for videos:

_quarto.yml

The configuration of a quarto project can be done in the yaml preamble of a .qmd file, or at the project-level in the _quarto.yml file:

project:
  type: website
  output-dir: ../docs

website:
  title: "Website"

  navbar:
    background: black
    pinned: true
    right:
      - text: "Slides"
        file: slides/presentation.html
      - icon: github
        href: https://github.com/vitay/quarto-website
        aria-label: GitHub

  sidebar:
    style: "docked"
    logo: img/tuc.png
    search: true
    contents:
      - text: "About"
        file: index.qmd
      - section: "Tutorial"
        contents:
        - Test.qmd

  page-footer:
    center: |
      Copyright Julien Vitay <julien.vitay@informatik.tu-chemnitz.de> - Chemnitz University of Technology

format:
  html:
    theme: [sandstone, ../assets/webpage.scss]
    page-layout: full
    smooth-scroll: true
    html-math-method: katex


bibliography: references.bib
csl: ../assets/frontiers.csl

highlight-style: github
code-line-numbers: false

Reveal.js slides

Reveal.js (https://revealjs.com/) is a javascript library allowing to create a slide deck in html+css+js.
pandoc/quarto is able to generate reveal.js slides from Markdown files.
Template at https://github.com/vitay/quarto-presentation

Websites

Websites are only in html and can comprise multiple pages, with a sidebar and topbar for navigation.
Template at https://github.com/vitay/quarto-website
Example at https://github.com/ANNarchy/ANNarchy.github.io and https://annarchy.github.io/

Books / theses

Books are websites with a focus on generating a nice pdf, such as a textbook or a thesis.
Template at https://github.com/vitay/quarto-thesis
Demo at https://julien-vitay.net/quarto-thesis and https://julien-vitay.net/habilitation

Article / reports

Articles / reports are single documents that can be exported to html and pdf (through LaTeX).
With the right LaTeX pandoc template, you can submit to any journal and have a html version of it.
Template at https://github.com/vitay/quarto-report
Demo at https://julien-vitay.net/quarto-report

Publishing quarto

quarto is html-centric, it generates html files in the docs/ directory (or anywhere).
The html pages can be hosted on github for free.
To visualize a preview:

quarto preview .

To render the files:

quarto render .

To push it to github:

quarto publish gh-pages

References

Scholl, C., Baladron, J., Vitay, J., and Hamker, F. H. (2022). Enhanced habit formation in Tourette patients explained by shortcut modulation in a hierarchical cortico-basal ganglia model. Brain Structure and Function. doi:10.1007/s00429-021-02446-x.

Vitay, J., Dinkelbach, H. Ü., and Hamker, F. H. (2015). ANNarchy: A code generation approach to neural simulations on parallel hardware. Frontiers in Neuroinformatics 9. doi:10.3389/fninf.2015.00019.
